LCD DIGITAL 60V / 100A WATT METER BATTERY BALANCE POWER VOLTAGE CHECKER ANALYZER FOR DC RC

LCD Digital 60V / 100A Watt Meter Battery Balance Power Voltage Checker Analyzer for DC RC Helicopter
This watt meter is an excellent addition to your RC hobby, DC circuits, solar system, boat / RV and battery backup systems! Great little gadget, very useful to monitor both charging and draining of batteries.
What a multipurpose Meter it is! A power meter, a volt meter, an amp-hour meter, ammeter and energy meter. Everything all in one unit! This is the perfect troubleshooting tool. This all-in-one watt meter is indispensable for analyzing, testing and troubleshooting any DIY DC power project.

Highlights:
● Digital LCD screen: Gives clear crisp number readings
● Handles up to 100 amps intermittently and 50 amps continuous duty
● Connecting load end to the battery provides real-time battery charging reading
● Handles 0 to 60 volts. Works on 12, 24, 36, and 48 volt battery bank systems
● Extremely low power consumption of 7mA. More efficient than any LED meter
● Measure energy ( Wh ) , charge ( Ah ) , power ( W ) , current ( A ) and voltage ( V )
● Accurate and precise 0.01 A current and 0.01 V voltage resolutions
● Measures peak Amps, peak Watts ( except for Doc Wattson ) and Voltage minimum ( sag )
● Rugged- handles 50A continuous and 100 A peak at 60V
● Acts like a wire so does not affect model's performance. Precision Alu-Chrom current sensing resistor, with only 0.001 Ohms resistance and circuitry that draws only 7mA
● Uses DSP to increase ADC resolution and differential measurement amplifiers to increase noise immunity

Specifications:
Voltage: ( 0 )V - 4V - 60V 0.01V ( Resolution )
Current: 0 - 100 A.P 0.01A ( Resolution )
Power: 0 - 6554 W 0.1W ( Resolution )
Charge: 0 - 65 Ah 0.001Ah ( Resolution )
Energy: 0 - 6554 Wh 0.1 Wh ( Resolution )
Measurement update period: 400ms
Signal sampling rate: samples / s
Data queue sequence time: 2 seconds
In circuit resistance: 0.001 Ohms
Operation Current: 7mA.
